Beta Draft Confidential
17-221/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring SVC Parameters
Configuring SVC Attributes
Screening Mode
Combination
Determines whether or not to process an ingress call at this
logical port.
Select the check box for one or more of the following
options:
Node Prefix — To screen the calling party against all of
the configured node prefixes. If a match is found, the call is
processed.
Port Prefix — To screen the calling party against all of the
configured port prefixes. If a match is found, the call is
processed.
Port Address — To screen the calling party against all of
the configured port addresses. If a match is found, the call
is processed.
Note: If you select more than one option, the ingress call is
processed if it meets one or more of the selected criteria
(for example, if you select both Node Prefix and Port
Address, the calling party address must match either a
valid node prefix or a valid port address).
Calling Party Presentation
Mode
Choose one of the following buttons:
User — Includes the calling party (connected number)
address at egress (ingress) based on the Presentation
Indicator in the SETUP (connect) message of the user’s
SVC request (confirm).
Always — Always includes the calling party (connected
number) address at egress (ingress), regardless of the
Presentation Indicator in the SETUP (connect) message of
the user’s SVC request (confirm).
Never — Never includes the calling party (connected
number) address at egress (ingress), regardless of the
Presentation Indicator in the SETUP (connect) message of
the user’s SVC request (confirm).
Table 17-6. Configure SVC: Address Tab Fields (Continued)
Field Description
