Beta Draft Confidential
Configuring SVC Parameters
Configuring SVC Attributes
ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000 1/19/0517-23
Transit Network Selection
Presentation Mode
Specifies whether or not to include the calling party
address on egress SVCs and processes the connected
number address in an ingress Connect message.
Choose one of the following egress presentation modes for
the logical port from the pull-down list:
Never Present — (default) Never signal TNS in egress
SVC requests.
Present Signaled TNS Only — Signal TNS in egress
SVC requests only if TNS was signaled by the user in the
ingress SVC request.
Signaled or Source Default — Signal TNS in egress SVC
requests if TNS was signaled by the user in the ingress
SVC request or a source default network ID was
provisioned at the ingress user’s logical port.
Note: Network IDs that do not match the adjacent network
ID (see the Adjacent Network field in Table 17-17 on
page 17-70) are processed according to the configured
presentation mode; however, a network ID that matches
the adjacent network ID will never be signaled in egress
calls (presentation mode is Never Present).
Screening Mode Choose one or more of the following screening modes for
the logical port from the pull-down list:
Ignore — Ignore the signaled TNS.
Accept — Always accept the signaled TNS.
Validate — (default) Screens the signaled TNS and
ignores it if there is no match.
Note: If you enable screening at any level, and the calling
party has no calling party address, the SVC fails unless
you set the Calling Party Ingress Address Insertion to
Insert or Replace, and configure a Calling Party Insertion
Address.
Table 17-6. Configure SVC: Address Tab Fields (Continued)
Field Description
