Beta Draft Confidential
17-481/19/05 ATM Services Configuration Guide for CBX 3500, CBX 500, GX 550, and B-STDX 9000
Configuring SVC Parameters
Configuring SVC Port Prefixes
For example, if you enter the partial address 51-43BF12AC (which uses 40 bits)
as the port prefix, but only need to check the first 38 bits of the port prefix for call
screening and call routing, select the 38 radio button.
4. If the port provides a network-to-network connection, see “Setting the Local and
Remote Gateway Address for Port Prefixes” on page 17-49 for instructions. When
done, proceed to step 5.
5. See Table 17-12 on page 17-53 to configure additional port prefix options.
6. Choose OK to save this port prefix and close the Add SVC Port Prefix dialog box.
Address you entered:
Address in binary (40 bits):
51-43BF12AC
01010001-01000011110011110001001010111100
Address in binary (38 bits):
01010001-010000111100111100010010101111
Address you entered:
Address in binary (40 bits):
51-43BF12A8
01010001-01000011110011110001001010111000
Address in binary (37 bits):
01010001-01000011110011110001001010111
