Rockwell Automation Publication 2198-UM004D-EN-P - December 2022 129
Chapter 7
Configure the Drive with KNX5100C Software
Before You Begin This section provides instructions to download and install KNX5100C
configuration software. It also provides procedures to launch KNX5100C and
configure your Kinetix® 5100 drive system with a Micro800™ controller by
using the Connected Components Workbenchâ„¢ software.
For help using the Connected Components Workbench as it applies to
configuring the Micro800 controllers, see Additional Resources
on page 14.
The Connected Components Workbench application, version 11.00 or later,
makes it possible to launch KNX5100C Configuration Tool and to configure a
Kinetix 5100 drive.
These procedures assume that you have wired your Kinetix 5100 drive system.
KNX5100C software is required for all applications. It is used to commission,
configure, and possibly program the Kinetix 5100 drive.
Topic Page
Before You Begin 129
Download KNX5100C Software 130
Connect to the Drive/Set Your COM Port 132
Configure Drive Settings 134
Set the IP Address 134
Configure the Motor Selection in KNX5100C Software 134
Parameter Editor 152
Choose an Operation Mode 156
Configure Settings 159
Configure Position, Velocity, and Current Loops 182
Digital I/O and Jog Function in KNX5100C Software 184
