Rockwell Automation Publication 2198-UM004D-EN-P - December 2022 31
Chapter 2
Plan and Install the Kinetix 5100 Drive System
This chapter describes system installation guidelines used in preparation for
mounting your Kinetix® 5100 drive components.
System Design Guidelines Use the information in this section when you design your enclosure and plan
to mount your system components on the panel.
For online product selection and system configuration tools, including
AutoCAD (DXF) drawings of the product, see
http://www.rockwellautomation.com/global/support/selection.page
.
System Mounting Requirements
• To comply with UL and CE and UK requirements, the Kinetix 5100 drive
system must be mounted in a grounded conductive enclosure offering
protection as defined in standard EN/IEC 60529 to IP20 such that they
are not accessible to an operator or unskilled person.
• To maintain the functional safety rating of the Kinetix 5100 drive system,
this enclosure must be appropriate for the environmental conditions of
the industrial location and provide a protection class of IP54 or higher.
• The panel you install inside the enclosure for mounting your system
components must be on a flat, rigid, vertical surface that won’t be
subjected to shock, vibration, moisture, oil mist, dust, or corrosive vapors
in accordance with pollution degree 2 (EN/IEC 61800-5-1) because the
product is rated to protection class IP20 (EN 60529).
• Size the drive enclosure so as not to exceed the maximum-ambient
temperature rating. Consider heat dissipation specifications for all drive
components.
Topic Page
System Design Guidelines 31
Electrical Noise Reduction 40
Mount Your Kinetix 5100 Drive 47
ATTENTION: Plan the installation of your system so that you can cut, drill,
tap, and weld with the system removed from the enclosure. Because the
system is of the open type construction, be careful to keep any metal debris
from falling into it. Metal debris or other foreign matter can become lodged
in the circuitry, which can result in damage to components.
