Rockwell Automation Publication 2198-UM004D-EN-P - December 2022 529
Appendix E
Use the Scope Function in KNX5100C Software
The Scope option provides you with a personal computer-based digital
oscilloscope function for real-time drive data monitoring. You can use two
scope modes (8K and 16K) to measure and monitor many signals quickly
without oscilloscope equipment.
Get Started To open the Scope dialog box, select Scope from the Function list.
Topic Page
Get Started 529
Scope Functions 530
Quick Setup of Communication Channels 530
Select Communication Channels 531
Enable Stop Condition 534
FFT Display and Show RMS Value 535
Fine-Tune the Scope 536
Set Preferences 537
Use Popup Menu for Save Options 538
