Rockwell Automation Allen-Bradley Kinetix 5100 User Manual

82 Rockwell Automation Publication 2198-UM004D-EN-P - December 2022
Chapter 4 Connect the Kinetix 5100 Drive System
Single-phase Input Power used with Single-phase Drives
These examples illustrate grounded single-phase power that is wired to single-
phase Kinetix 5100 drives.
Figure 47 - Single-phase (200…230V) Grounded Power Configuration
Figure 48 - Single-phase (120V) Grounded Power Configuration
Figure 49 - Single-phase (230V) Grounded Power Configuration
L2
L1
L2
L1
L2
L1
L2
L1
E
L1C
L2C
Transformer Secondary
Bonded Cabinet Ground Bus
Ground Grid or
Power Distribution Ground
AC Line
Filter
200…230V AC
Output
Circuit
Protection
Circuit
Protection
Mains AC Input
Power Connector
Control AC Input
Power Connector
2198-E1004-ERS, 2198-E1007-ERS,
2198-E1015-ERS, and 2198-E1020-ERS
Drives with Single-phase Operation
Reducing the transformer output reduces motor speed. Feeder and branch short-circuit protection is not illustrated.
L2
L1 (Neutral)
L2
L1
L2
L1
L2
L1
E
L1C
L2C
Transformer Secondary
Bonded Cabinet Ground Bus
Ground Grid or
Power Distribution Ground
AC Line
Filter
120V AC
Output
Circuit
Protection
Mains AC Input
Power Connector
Control AC Input
Power Connector
Circuit
Protection
2198-E1004-ERS, 2198-E1007-ERS,
2198-E1015-ERS, and 2198-E1020-ERS
Drives with Single-phase Operation
L2
L1 (Neutral)
L2
L1
L2
L1
L2
L1
E
L1C
L2C
Transformer Secondary
Bonded Cabinet Ground Bus
Ground Grid or
Power Distribution Ground
AC Line
Filter
230V AC
Output
Circuit
Protection
Mains AC Input
Power Connector
Control AC Input
Power Connector
Circuit
Protection
2198-E1004-ERS, 2198-E1007-ERS,
2198-E1015-ERS, and 2198-E1020-ERS
Drives with Single-phase Operation
