198 Rockwell Automation Publication 2198-UM004D-EN-P - December 2022
Chapter 8 Configure the Drive in Studio 5000 Logix Designer Application
Download the Program When the Logix Designer application development is complete, the file is
saved. You must download your program to the Logix 5000 controller.
For legacy applications, we have developed some sample logic that you can use
to import the entire Add-On Instruction library into your Studio 5000 Logix
Designer application by using an .L5X file as the import mechanism. See
Appendix C on page 489
for details on the Add-On Instruction library.
For new applications, use the Logix Designer application with the Plug-in
Wizard once the Power Device library (which includes the new Add-On
Instructions) is downloaded from the PCDC
site.
