154 Rockwell Automation Publication 2198-UM004D-EN-P - December 2022
Chapter 7 Configure the Drive with KNX5100C Software
Parameter Wizard
Double-click a parameter value to open the parameter wizard, which provides
a simple method to change parameter values.
Parameter Toolbar
The toolbar at the top of Parameter Editor contains six icons.
The function of each icon is as follows.
Save Parameters File
All Kinetix 5100 parameters that are shown on the screen (which are those also
saved to your personal computer) are saved as a *.par file.
Open Parameter File
All Kinetix 5100 parameter files (.par) on your personal computer can be
opened and displayed.
Read Parameters
All Kinetix 5100 parameters are read.
Download Parameters
When online with the Kinetix 5100 drive, a dialog box lets you choose to
download all the parameters or just the parameters that have been modified.
Stop Operation
This stops any operation in progress.
