34 Rockwell Automation Publication 2198-UM004D-EN-P - December 2022
Chapter 2 Plan and Install the Kinetix 5100 Drive System
Table 6 - Input Power UL/CSA Circuit-protection Specifications
Kinetix 5100 Drive
Cat. No.
Drive Voltage
Fuses (Bussmann)
Cat. No.
Miniature CB
(1)
Cat. No.
Molded Case CB
Cat. No.
2198-E1004-ERS
120V/230V, single-phase KTK-R-15 (15 A) 1489-M2D100 –
230V, three-phase KTK-R-10 (10 A) 1489-M3D100 –
2198-E1007-ERS
120V/230V, single-phase KTK-R-20 (20 A) 1489-M2D200 –
230V, three-phase KTK-R-15 (15 A) 1489-M3D130 –
2198-E1015-ERS
120V/230V, single-phase KTK-R-30 (30 A) 1489-M2D300 –
230V, three-phase KTK-R-25 (25 A) 1489-M3D200 –
2198-E1020-ERS
120V/230V, single-phase LPJ-40SP (40 A) 1489-M2D400 –
230V, three-phase LPJ-35SP (35 A) 1489-M3D300 –
2198-E2030-ERS
230V, three-phase
LPJ-50SP (50 A) 1489-M3D350 –
2198-E2055-ERS LPJ-70SP (70 A) 1489-M3D600 –
2198-E2075-ERS LPJ-80SP (80 A) – 140G-G2C3-C70
2198-E2150-ERS LPJ-125SP (125 A) – 140G-G2C3-D12
2198-E4004-ERS
380…480V AC, three-phase
KTK-R-10 (10A) 1489-M3D100 –
2198-E4007-ERS KTK-R-15 (15A) 1489-M3D100 –
2198-E4015-ERS KTK-R-20 (20A) 1489-M3D150 –
2198-E4020-ERS KTK-R-25 (25A) 1489-M3D200 –
2198-E4030-ERS KTK-R-30 (30A) 1489-M3D300 –
2198-E4055-ERS LPJ-35SP (35A) 1489-M3D350 –
2198-E4075-ERS LPJ-45SP (45A) – 140G-G6C3-C45
2198-E4150-ERS LPJ-90SP (90A) – 140G-G6C3-C60
(1) There are no recommended motor-protection circuit breakers for the Kinetix 5100 servo drives.
Table 7 - Input Power IEC (non-UL/CSA) Circuit-protection Specifications
Kinetix 5100 Drive
Cat. No.
Drive Voltage
DIN gG Fuses
Amps, Max
Miniature CB
(1)
Cat. No.
Molded Case CB
Cat. No.
2198-E1004-ERS
120V/230V, single-phase 15 1489-M2D100 –
230V, three-phase 10 1489-M3D100 –
2198-E1007-ERS
120V/230V, single-phase 20 1489-M2D200 –
230V, three-phase 15 1489-M3D130 –
2198-E1015-ERS
120V/230V, single-phase 30 1489-M2D300 –
230V, three-phase 25 1489-M3D200 –
2198-E1020-ERS
120V/230V, single-phase 40 1489-M2D400 –
230V, three-phase 35 1489-M3D300 –
2198-E2030-ERS
230V, three-phase
50 1489-M3D350 –
2198-E2055-ERS 70 1489-M3D600 –
2198-E2075-ERS 80 – 140G-G2C3-C70
2198-E2150-ERS 125 – 140G-G2C3-D12
2198-E4004-ERS
380…480V AC, three-phase
10 1489-M3D100 –
2198-E4007-ERS 15 1489-M3D100 –
2198-E4015-ERS 20 1489-M3D150 –
2198-E4020-ERS 25 1489-M3D200 –
2198-E4030-ERS 30 1489-M3D300 –
2198-E4055-ERS 35 1489-M3D350 –
2198-E4075-ERS 45 – 140G-G6C3-C45
2198-E4150-ERS 90 – 140G-G6C3-C60
(1) There are no recommended motor protection circuit breakers for the Kinetix 5100 servo drives.
