Rockwell Automation Publication 2198-UM004D-EN-P - December 2022 37
Chapter 2 Plan and Install the Kinetix 5100 Drive System
With no active method of heat dissipation (such as fans or air conditioning),
either of the following approximate equations can be used.
If the maximum ambient rating of the Kinetix 5100 drive system is 50 °C
(122 °F) and if the maximum environmental temperature is 20 °C (68 °F), then
T=30. In this example, the total heat dissipation is 416 W (sum of all
components in enclosure). So, in the equation below, T=30 and Q=416.
In this example, the enclosure must have an exterior surface of at least 2.99 m
2
.
If any portion of the enclosure is not able to transfer heat, do not include that
value in the calculation.
Because the minimum cabinet depth to house the Kinetix 5100 system
(selected for this example) is 300 mm (11.8 in.), the cabinet needs to be
approximately 1500 x 700 x 300 mm (59.0 x 27.6 x 11.8 in.) HxWxD.
1.5 x (0.300 x 0.70) + 1.5 x (0.300 x 2.0) + 1.5 x (0.70 x 2.0) = 3.31 m
2
Because this cabinet size is considerably larger than what is necessary to house
the system components, it can be more efficient to provide a means of cooling
in a smaller cabinet. Contact your cabinet manufacturer for options available
to cool your cabinet.
Table 10
provides total power dissipation for Kinetix 5100 drives, three-phase
operation, with 100% rated current and speed.
Metric Standard English
Where T is temperature difference between inside air
and outside ambient (°C), Q is heat that is generated in
enclosure (Watts), and A is enclosure surface area (m
2
).
The exterior surface of all six sides of an enclosure is
calculated as
Where T is temperature difference between inside air
and outside ambient (°F), Q is heat that is generated in
enclosure (Watts), and A is enclosure surface area (ft
2)
.
The exterior surface of all six sides of an enclosure is
calculated as
A = 2dw + 2dh + 2wh A = (2dw + 2dh + 2wh) /144
Where d (depth), w (width), and h (height) are in meters. Where d (depth), w (width), and h (height) are in inches.
A =
0.38 (416)
1.8 (30) - 1.1
= 2.99 m
2
Table 10 - Power Dissipation Specifications
Kinetix 5100 (200V-class)
Drives
Cat. No.
Loss (230V), max
W
Kinetix 5100 (400V-class) Drives
Cat. No.
Loss (380V), max
W
Loss (480V), max
W
2198-E1004-ERS 38.06 2198-E4004-ERS 51 56
2198-E1007-ERS 66.33 2198-E4007-ERS 71 86
2198-E1015-ERS 87.23 2198-E4015-ERS 99 117
2198-E1020-ERS 139.83 2198-E4020-ERS 109 123
2198-E2030-ERS 179.53 2198-E4030-ERS 214 220
2198-E2055-ERS 328.52 2198-E4055-ERS 342 363
2198-E2075-ERS 372.33 2198-E4075-ERS 467 494
2198-E2150-ERS 648.55 2198-E4150-ERS 501 541
