Rockwell Automation Publication 2198-UM004D-EN-P - December 2022 483
Appendix B Upgrade Kinetix 5100 Drive Firmware
7. Type the IP address of your Ethernet Module or Controller that bridges
between the Ethernet network and the EtherNet/IP network.
8. Click OK.
The new Ethernet driver appears under Configured Drivers.
9. Click Close.
10. Minimize the RSLinx application dialog box.
Start the ControlFLASH Software
Follow these steps to start ControlFLASH software and begin your firmware
upgrade.
1. In the Logix Designer application, from the Tools menu, choose
ControlFLASH.
2. In the Logix Designer application, from the Tools menu, choose
ControlFLASH.
The Welcome to ControlFLASH dialog box appears.
3. Click Next.
You can also open ControlFLASH software by choosing
Start>Programs>FLASH Programming Tools>ControlFLASH.
