Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 1 Shelf Assembly Hardware
1.12.2 Fiber Management Using the Patch-Panel Trays
Figure 1-43 Patch-Panel Port Wavelengths
1.12.2.2 40-Channel Patch-Panel Tray
The 40-channel patch panel tray is 2 RUs deep and comes preinstalled with MPO-LC cables. The
40-channel patch-panel tray can host up to 10 ribbon cables (with eight fibers each), for a total of 80
connections, and is used with expanded ROADM, terminal, hub, and mesh nodes. Expanded hub and
ROADM nodes will typically require two 40-channel patch-panel modules each; terminal nodes require
one 40-channel patch-panel tray; and one 40-channel patch-panel tray is needed for mesh nodes for each
direction.
The module fits 19- and 23-inch (482.6-mm and 584.2-mm) ANSI racks and 600 mm (23.6 inch) x
300 mm (11.8 inch) ETSI racks, using reversible brackets.
Figure 1-44 shows a 40-channel patch-panel tray.
RX T X RX T X RX T X RX T X
1532.6nm
1536.6nm
1531.8nm 1531.1nm 1530.3nm
1535.8nm 1535.0nm 1534.2nm
RX T X RX T X RX T X RX T X
1540.5nm
1544.5nm
1539.7nm 1538.9nm 1538.1nm
1543.7nm 1542.9nm 1542.1nm
RX T X RX T X RX T X RX T X
RX T X RX T X RX T X RX T X
1548.5nm
1552.5nm
1547.7nm 1546.9nm 1546.1nm
1551.7nm 1550.9nm 1550.1nm
RX T X RX T X RX T X RX T X
RX T X RX T X RX T X RX T X
1556.5nm
1560.6nm
1555.7nm 1554.9nm 1554.1nm
1559.7nm 1558.9nm 1558.1nm
RX T X RX T X RX T X RX T X
RX T X RX T X RX T X RX T X
144676
13254768
