Chapter 7 Reconfigurable Optical Add/Drop Cards
7.1.2 Card Compatibility
7.1.2 Card Compatibility
Table 7-2 lists the Cisco Transport Controller (CTC) software compatibility for the ROADM cards.
7.1.3 Interface Classes
The 40-MUX-C, 32DMX, 32DMX-L, 40-DMX-C, 40-DMX-CE, 32WSS, and 32WSS-L cards have
different input and output optical channel signals depending on the interface card originating the input
signal. The input interface cards have been grouped in classes listed in Table 7-3. The subsequent tables
list the optical performance and output power of each interface class.
40-WXC-C
The 40-WXC-C card has five sets of ports
located on the faceplate. It operates in
Slots 1 to 5 and 12 to 16.
See the “7.12 40-WXC-C Card”
section on page 7-63
MMU
The MMU card has six sets of ports located
on the faceplate, It operates in Slots 1 to 6
and 12 to 17.
See the “7.13 MMU Card”
section on page 7-69
Table 7-1 ROADM Card Summary (continued)
Card Port Description For Additional Information
Table 7-2 Software Release Compatibility for ROADM Cards
Card Name R4.5 R4.6 R4.7 R5.0 R6.0 R7.0 R7.2 R8.0 R8.5
32WSS No No Yes Yes Yes Yes Yes Yes Yes
32WSS-L NoNoNoNoNoYesYesYesYes
40-WSS-C NoNoNoNoNoNoNoYesYes
40-WSS-CE No No No No No No No Yes Yes
32DMX No No Yes Yes Yes Yes Yes Yes Yes
32DMX-L NoNoNoNoNoYesYesYesYes
40-DMX-C No No No No No No No Yes Yes
40-DMX-CENoNoNoNoNoNoNoYesYes
40-MUX-C No No No No No No No Yes Yes
40-WXC-C No No No No No No No Yes Yes
MMU NoNoNoNoNoYesYesYesYes
