8-42
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 8 Transponder and Muxponder Cards
8.8.11 Wavelength Identification
Table 8-19 describes the required trunk transmit laser wavelengths for the MXP_2.5G_10E_L card. The
laser is fully tunable over 80 wavelengths in the L band at 50-GHz spacing on the ITU grid.
36 194.25 1543.333 77 192.20 1559.794
37 194.20 1543.730 78 192.15 1560.200
38 194.15 1544.128 79 192.10 1560.606
39 194.10 1544.526 80 192.05 1561.013
40 194.05 1544.924 81 192.00 1561.42
41 194.00 1545.32 82 191.95 1561.83
Table 8-18 MXP_2.5G_10E_C Trunk Wavelengths (continued)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Table 8-19 MXP_2.5G_10E_L Trunk Wavelengths
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
1 190.85 1570.83 41 188.85 1587.46
2 190.8 1571.24 42 188.8 1587.88
3 190.75 1571.65 43 188.75 1588.30
4 190.7 1572.06 44 188.7 1588.73
5 190.65 1572.48 45 188.65 1589.15
6 190.6 1572.89 46 188.6 1589.57
7 190.55 1573.30 47 188.55 1589.99
8 190.5 1573.71 48 188.5 1590.41
9 190.45 1574.13 49 188.45 1590.83
10 190.4 1574.54 50 188.4 1591.26
11 190.35 1574.95 51 188.35 1591.68
12 190.3 1575.37 52 188.3 1592.10
13 190.25 1575.78 53 188.25 1592.52
14 190.2 1576.20 54 188.2 1592.95
15 190.15 1576.61 55 188.15 1593.37
16 190.1 1577.03 56 188.1 1593.79
17 190.05 1577.44 57 188.05 1594.22
18 190 1577.86 58 188 1594.64
19 189.95 1578.27 59 187.95 1595.06
20 189.9 1578.69 60 187.9 1595.49
21 189.85 1579.10 61 187.85 1595.91
22 189.8 1579.52 62 187.8 1596.34
23 189.75 1579.93 63 187.75 1596.76
