Cisco ONS 15454 DWDM Reference Manual

A-32
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.7.8 40-WSS-C Card Specifications
The 40-WSS-C card channel grid is listed in Table A-18.
Insertion loss All SOP and within
whole operating
temperature range
EXP_RX to
COM_TX
—7.5dB
EXP_RX to
COM_TX
—2.3dB
EXP_RX to
COM_TX
—6.0dB
EXP_RX to
COM_TX
—6.8dB
VOA dynamic range — EXP_RX to
COM_TX
20 — dB
EXP_RX to
COM_TX
25 — dB
Maximum optical
input power
— — 300 — mW
Table A-17 40-WSS-C Optical Specifications (continued)
Parameter Note Condition Min Max Unit
Table A-18 40-WSS-C Channel Grid
Band ID Channel Label Frequency (THz) Wavelength (nm)
B30.3 30.3 195.9 1530.33
31.1 195.8 1531.12
31.9 195.7 1531.90
32.6 195.6 1532.68
33.4 195.5 1533.47
B34.2 34.2 195.4 1534.25
35.0 195.3 1535.04
35.8 195.2 1535.82
36.6 195.1 1536.61
37.4 195.0 1537.4
B38.1 38.1 194.9 1538.19
38.9 194.8 1538.98
39.7 194.7 1539.77
40.5 194.6 1540.56
41.3 194.5 1541.35

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
