1-24
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 1 Shelf Assembly Hardware
1.6 Front Door
Figure 1-21 shows how to remove the ONS 15454 ANSI front door.
Figure 1-21 Removing the ONS 15454 ANSI Front Door
Door hinge
Assembly hinge pin
Assembly hinge
Translucent
circles
for LED
viewing
38831
FAN FAIL
CRIT
MAJ
MIN
