Appendix A Hardware Specifications
A.8.3 AD-4C-xx.x Card Specifications
The AD-2C-xx.x card optical input and output power varies with amplifier output levels and the class of
transponder interfaces used. See Table 6-3 on page 6-3 through Table 6-6 on page 6-5 for this
information.
The AD-2C-xx.x has the following additional specifications:
• Dimensions
– Height: 12.650 in. (321.3 mm)
– Width: 0.921 in. (23.4 mm) (The dimension of the finger gasket is not included)
– Depth: 9.0 in. (228.6 mm)
A.8.3 AD-4C-xx.x Card Specifications
Table A-25 lists the AD-4C-xx.x optical specifications.
VOA dynamic range — — 30 — dB
Maximum optical
input power
— — 300 — mW
Table A-24 AD-2C-xx.x Card Optical Specifications (continued)
Parameter Note Condition Min Max Unit
Table A-25 AD-4C-xx.x Optical Specifications
Parameter Note Condition Min Max Unit
Channel grid See Table A-26. The channel
plan for the AD-4C-xx.x card is
identical to the channel plan for
the AD-1B-xx.x card.
————
Trx filter shape
(–0.5 dB
bandwidth)
TrxBW
2
All SOP and within whole
operating temperature range
COM Rx—xx.xx Tx
COM Rx
—yy.yy Tx
COM Rx—zz.zz Tx
COM Rx—kk.kk Tx
xx.xx Rx—COM Tx
yy.yy Rx—COM Tx
+/–180 — pm
Rfx filter shape
(–1 dB bandwidth)
RfxBW
2
All SOP and within whole
operating temperature range
COM Rx—Exp Tx
Exp Rx—COM Tx
——pm
Insertion loss
(drop section)
All SOP and within whole
operating temperature range
(two connectors included)
COM Rx—xx.xx Tx — 5.5 dB
COM Rx—yy.yy Tx — 5.0 dB
COM Rx—zz.zz Tx — 4.5 dB
COM Rx—kk.kk Tx — 4.1 dB
Insertion loss
(express section)
VOA at minimum attenuation;
all SOP and within whole
operating temperature range
(two connectors included)
COM Rx—Exp Tx — 2.7 dB
Exp Rx—COM Tx — 1.2 dB
