Cisco ONS 15454 DWDM Reference Manual

6-5
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 6 Optical Add/Drop Cards
6.1.4 DWDM Card Channel Allocation Plan
6.1.4 DWDM Card Channel Allocation Plan
ONS 15454 DWDM channel OADM and band OADM cards are designed for use with specific channels
in the C band. In most cases, the channels for these cards are either numbered (for example, 1 to 32) or
delimited (odd or even). Client interfaces must comply with these channel assignments to be compatible
with the ONS 15454 system.
Table 6-6 lists the channel IDs and wavelengths assigned to the C-band DWDM channels.
Note In some cases, a card uses only some or all of the channels listed in a band. Also, some cards use channels
on the 100-GHz ITU-T grid while others use channels on the 50-GHz ITU-T grid. See specific card
descriptions in Appendix A, “Hardware Specifications,” for more details.
Power sensitivity –31
dBm
–25
dBm
–30
dBm
–23
dBm
–24 dBm –27
dBm
–33
dBm
–28 dBm –18 dBm –26 dBm
Power overload –9 dBm –9 dBm –9 dBm –9 dBm –7 dBm –17dBm
Transmitted Power Range
1
TXP_MR_2.5G –1.0 to 1.0 dBm –1.0 to 1.0 dBm –1.0 to
1.0 dBm
–2.0 to 0 dBm — —
TXPP_MR_2.5G –4.5 to –2.5 dBm –4.5 to –2.5 dBm –4.5 to
–2.5 dBm
MXP_MR_2.5G — +2.0 to +4.0 dBm —
MXPP_MR_2.5G — –1.5 to +0.5 dBm —
2/4 port GbE
Transponder (GBIC
WDM 100GHz)
— — — — +2.5 to
3.5 dBm —
Dispersion
compensation
tolerance
–1200 to
+5400 ps/nm
–1200 to
+5400 ps/nm
–1200 to
+3300
ps/nm
–1200 to
+3300 ps/nm
–1000 to +3600
ps/nm
–1000 to
+3200
ps/nm
1. These values, decreased by patchcord and connector losses, are also the input power values for the OADM cards.
Table 6-5 2.5-Gbps Interface Optical Performance (continued)
Parameter Class D Class E Class F Class G Class H Class J
Type
Power
Limited
OSNR
Limited
(if appl.)
Power
Limited
OSNR
Limited
(if
appl.)
OSNR
Limited
Power
Limited
OSNR
Limited
(if appl.)
Power
Limited
OSNR
Limited
(if appl.)
Power
Limited
Table 6-6 DWDM Channel Allocation Plan (C Band)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
1 196.00 1529.55 42 193.95 1545.72
2 195.95 1529.94 43 193.90 1546.119
3 195.90 1530.334 44 193.85 1546.518

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
