Cisco ONS 15454 DWDM Reference Manual

7-58
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 7 Reconfigurable Optical Add/Drop Cards
7.11.2 40-WSS-CE Card Block Diagram
Figure 7-30 40-WSS-CE Faceplate
7.11.2 40-WSS-CE Card Block Diagram
Figure 7-31 shows a block diagram of the 40-WSS-CE card.
240643
40-WSS-C
37.0 - 42.5 30.7 - 36.243.3 - 48.949.7 - 55.356.2 - 61.8
ADD RX
COM
RX TX
EXP
RX TX
DROP
TX
FAIL
ACT
SF

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
