Appendix A Hardware Specifications
A.7.10 40-WXC-C Card Specifications
The 40-WSS-CE card has the following additional specifications:
• Dimensions
– Height: 8.66 in. (220 mm)
– Width: 1.866 in. (47.4 mm) (The dimension of the finger gasket is not included)
– Depth: 1.42 in. (36 mm)
A.7.10 40-WXC-C Card Specifications
The 40-WXC-C card optical specifications are listed in Table A-21.
Note For power specifications, see Table A-2 on page A-6.
The 40-WXC-C card has the following additional specifications:
• Dimensions
– Height: 12.65 in. (321.3 mm) for a standard DWDM unit
B58.6 58.6 192.35 1558.58
59.4 192.25 1559.39
60.2 192.15 1560.20
61.0 192.05 1561.01
61.8 191.95 1561.83
Table A-20 40-WSS-C Card Channel Grid (continued)
Band ID Channel Label Frequency (THz) Wavelength (nm)
Table A-21 40-WXC-C Optical Specifications
Parameter Note Condition Min Max Unit
Channel bandwidth:
–0.25 dB
All SOP and within
whole operating
temperature range
All paths — — GHz
Channel bandwidth:
–0.5 dB
+/- 20.5 — GHz
Channel bandwidth:
–1.5 dB
— — GHz
Channel bandwidth:
–03.0 dB
+/- 37.5 — GHz
Insertion loss All SOP and within
whole operating
temperature range
All paths — 8.5 dB
VOA dynamic range — All paths 20 — dB
Maximum optical
input power
— — 300 — mW

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
