A.10.2 PP-MESH-8 Patch Panel Specifications
– Operating temperature: +23 to +149 degrees Fahrenheit (–5 to +65 degrees Celsius)
– Operating humidity: 5 to 95 percent, noncondensing
• Dimensions
– Height: 17.42 in. (442.5 mm)
– Width: 3.457 in. (87.8 mm)
– Depth: 11.025 in. (280 mm)
A.10.2 PP-MESH-8 Patch Panel Specifications
The PP-MESH-8 patch panel optical specifications are listed in Table A-48.
The PP-MESH-8 patch panel has the following additonal specifications:
• Environmental
– Operating temperature: +23 to +149 degrees Fahrenheit (–5 to +65 degrees Celsius)
– Operating humidity: 5 to 95 percent, noncondensing
• Dimensions
– Height: 17.42 in. (442.5 mm)
– Width: 3.457 in. (87.8 mm)
– Depth: 11.025 in. (280 mm)
Table A-48 PP-MESH-8 Patch Panel Optical Specifications
Parameter Note Condition Min Max Unit
Wavelength range — — 1530 1570 nm
Insertion loss
1 2
1. Under all SOPs and all operating environmental conditions
2. Values are referenced with connector loss (LC=0.3 dB, MPO=0.5dB)
— In all the wavelength
ranges
(local ADD or test
access RX to EXP TX,
COM RX to EXP TX,
COM RX to test access
TX)
— 10.6 dB
Insertion loss
uniformity
1 2
— In all the wavelength
ranges
—1.3dB
PDL
1
—— —0.5dB
PMD
1
—— —0.1dB
Optical Return Loss
1
—— 50—dB
Directivity
1
—— 50—dB

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
