Chapter 1 Shelf Assembly Hardware
1.16.2 Card Replacement
Table 1-16 shows the slot and card symbol definitions.
1.16.2 Card Replacement
To replace an ONS 15454 card with another card of the same type, you do not need to make any changes
to the database; remove the old card and replace it with a new card. To replace a card with a card of a
different type, physically remove the card and replace it with the new card, then delete the original card
from CTC. For specifics, refer to the “Maintain the Node” chapter in the Cisco ONS 15454 DWDM
Procedure Guide.
Caution Removing any active card from the ONS 15454 can result in traffic interruption. Use caution when
replacing cards and verify that only inactive or standby cards are being replaced. If the active card needs
to be replaced, switch it to standby prior to removing the card from the node. For traffic switching
procedures, refer to the Cisco ONS 15454 DWDM Procedure Guide.
Note An improper removal (IMPROPRMVL) alarm is raised whenever a card pull (reseat) is performed,
unless the card is deleted in CTC first. The alarm clears after the card replacement is complete.
Table 1-16 Slot and Card Symbols
Symbol Color/Shape Definition
Orange/Circle Slots 1 to 6 and 12 to 17. Only install cards with a circle symbol on the faceplate.
Blue/Triangle Slots 5, 6, 12, and 13. Only install cards with circle or a triangle symbol on the
faceplate.
Purple/Square TCC2/TCC2P slot, Slots 7 and 11. Only install cards with a square symbol on
the faceplate.
Green/Cross Cross-connect (XC/XCVT/XC10G) slot, Slots 8 and 10. Only install
ONS 15454 cards with a cross symbol on the faceplate.
Note Cross-connect cards are not required in DWDM applications. Install a
FILLER card or blank card if not using Slots 8 and 10.
Red/P Protection slot in 1:N protection schemes.
Red/Diamond AIC/AIC-I slot, Slot 9. Only install cards with a diamond symbol on the
faceplate.
Gold/Star Slots 1 to 4 and 14 to 17. Only install cards with a star symbol on the faceplate.
Blue/Hexagon (Only used with the 15454-SA-HD shelf assembly.) Slots 3 and 15. Only install
ONS 15454 ANSI cards with a blue hexagon symbol on the faceplate.
