Cisco ONS 15454 DWDM - Table 12-8 Multishelf View Tabs and Subtabs; Table 12-9 Node View (Single-Shelf Mode) or Shelf View (Multishelf Mode) Tabs and Subtabs

12-14
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 12 Cisco Transport Controller Operation
12.5.2 Node View (Multishelf Mode), Node View (Single-Shelf Mode), and Shelf View (Multishelf Mode)
12.5.2.5 Node View (Single-Shelf Mode) or Shelf View (Multishelf Mode) Tabs
Table 12-9 lists the tabs and subtabs available in node view (single-shelf mode) or shelf view (multishelf
mode).
Inventory Provides inventory information (part number,
serial number, and Common Language
Equipment Identification [CLEI] codes) for
cards installed on all shelves in the multishelf
node. Allows you to delete and reset cards and
change the card service state.
—
Maintenance Performs maintenance tasks for the multishelf
node.
Database, Network, OSI, Software,
Diagnostic, Audit, DWDM
Table 12-8 Multishelf View Tabs and Subtabs (continued)
Tab Description Subtabs
Table 12-9 Node View (Single-Shelf Mode) or Shelf View (Multishelf Mode) Tabs and Subtabs
Tab Description Subtabs
Alarms Lists current alarms (CR, MJ, MN) for the node
or shelf and updates them in real time.
—
Conditions Displays a list of standing conditions on the
node or shelf.
—
History Provides a history of node or shelf alarms
including the date, type, and severity of each
alarm. The Session subtab displays alarms and
events for the current session. The Node subtab
displays alarms and events retrieved from a
fixed-size log on the node.
Session, Node
Circuits Creates, deletes, edits, and maps circuits. Circuits, Rolls
Provisioning Provisions the ONS 15454 single-shelf or
multishelf node.
Single-shelf mode: General,
Network, OSI, Security, SNMP,
Comm Channels, Alarm Profiles,
Defaults, WDM-ANS
Multishelf mode: General,
Protection, Timing, Alarm Profiles
