Chapter 4 Optical Amplifier Cards
4.1.1 Card Summary
• Optical Booster Enhanced amplifier (OPT-BST-E)
• Optical Booster L-Band amplifier (OPT-BST-L)
• Optical L-Band preamplifier (OPT-AMP-L)
• Optical C-Band amplifier (OPT-AMP-17-C).
• Optical C-band high-gain high-power amplicier (OPT-AMP-C)
Note The OPT-AMP-L preamplifier, OPT-AMP-C and OPT-AMP-17-C amplifiers are software-configurable
as a preamplifier or as a booster amplifier.
Optical amplifier card architecture includes an optical plug-in module with a controller that manages
optical power, laser current, and temperature control loops. An amplifier also manages communication
with the TCC2/TCC2P card and operation, administration, maintenance, and provisioning (OAM&P)
functions such as provisioning, controls, and alarms.
4.1.1 Card Summary
Table 4-1 lists and summarizes the functions of each optical amplifier card.
Table 4-1 Optical Amplifier Cards for the ONS 15454
Card Port Description For Additional Information
OPT-PRE
The OPT-PRE amplifier has five optical
ports (three sets) located on the faceplate. It
operates in Slots 1 to 6 and 12 to 17.
See the “4.3 OPT-PRE
Amplifier Card” section on
page 4-5.
OPT-BST
The OPT-BST amplifier has four sets of
optical ports located on the faceplate. It
operates in Slots 1 to 6 and 12 to 17.
See the “4.4 OPT-BST
Amplifier Card” section on
page 4-9.
OPT-BST-E
The OPT-BST-E amplifier has four sets of
optical ports located on the faceplate. It
operates in Slots 1 to 6 and 12 to 17.
See the “4.5 OPT-BST-E
Amplifier Card” section on
page 4-13.
OPT-BST-L
The OPT-BST-L L-band amplifier has four
sets of optical ports located on the faceplate.
It operates in Slots 1 to 6 and 12 to 17.
See the “4.6 OPT-BST-L
Amplifier Card” section on
page 4-17.
OPT-AMP-L
The OPT-AMP-L L-band preamplifier have
five sets of optical ports located on the
faceplate. It is a two-slot card that operates
in Slots 1 to 6 and 12 to 17.
See the “4.7 OPT-AMP-L Card”
section on page 4-21.

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
