Chapter 17 Performance Monitoring
17.2.2 Payload PM Window
Table 17-7 lists the FC client-side payload PM parameters. FC payload PMs are available on the FC port
on both the MXP_MR_2.5G and the MXPP_MR_2.5G cards when the FC1G client type is enabled. For
PPM provisioning procedures, refer to the Cisco ONS 15454 DWDM Procedure Guide. For payload
definitions, see the “17.6 Full RMON Statistics PM Parameter Definitions” section on page 17-23.
Table 17-8 lists the Transparent Generic Framing Procedure (GFP-T) payload PMs. The GFP-T payload
PMs are available on the GFP port on both the MXP_MR_2.5G and the MXPP_MR_2.5G cards when
the ONE_GE or the 1 FC client type is enabled. GFP-T payload PMs are also available on the client port
on both the MXP_MR_2.5G and the MXPP_MR_2.5G cards when the 1 FC client type is enabled. For
PPM provisioning procedures, refer to the Cisco ONS 15454 DWDM Procedure Guide. For payload
definitions, see the “17.6 Full RMON Statistics PM Parameter Definitions” section on page 17-23.
Table 17-6 ONE_GE or FC1G Payload PMs for the MXP_MR_2.5G and MXPP_MR_2.5G Cards
ONE_GE or FC1G Payload Performance Parameters
8b10bInvalidOrderedSets
8b10bStatsEncodingDispErrors
ifInDiscards
ifInErrors
ifInOctets
ifOutDiscards
ifOutOctets
mediaIndStatsRxFramesBadCRC
mediaIndStatsRxFramesTooLong
mediaIndStatsRxFramesTruncated
mediaIndStatsTxFramesBadCRC
rxTotalPkts
txTotalPkts
Table 17-7 FC1G Payload PMs on the Client Side
FC1G Payload PMs on the Client Port
fcStatsLinkRecoveries
fcStatsRxCredits
fcStatsTxCredits
fcStatsZeroTxCredits
gfpStatsRoundTripLatencyUSec
gfpStatsRxDistanceExtBuffers
gfpStatsTxDistanceExtBuffers
Table 17-8 GFP-T Payload PMs
GFP-T Payload PMs on the GFP Port
gfpStatsCSFRaised
gfpStatsLFDRaised
gfpStatsRxCRCErrors
gfpStatsRxMBitErrors
gfpStatsRxSBitErrors
gfpStatsRxTypeInvalid
