7.7.4 40-DMX-C Power Monitoring
For other cards’ ROADM functionality, see that card’s description in this chapter. For a diagram of a
typical ROADM configuration, see the “9.1.4 ROADM Node” section on page 9-12.
7.7.4 40-DMX-C Power Monitoring
Physical photodiodes P1 through P40 monitor the power at the outputs of the 40-DMX-C card. P41
monitors the total multiplexed power at the input, calibrated to the COM-RX port. Table 7-20 shows the
returned power level values calibrated to each port.
7.7.5 40-DMX-C Channel Plan
Table 7-21 shows the 40 ITU-T 100-GHz-spaced, C band channels (wavelengths) that are demultiplexed
by the 40-DMX-C card.
Table 7-20 40-DMX-C Port Calibration
Photodiode CTC Type Name Calibrated to Port
P1–P40 DROP DROP TX
P41 INPUT COM COM RX
Table 7-21 40-DMX-C Channel Plan
Band ID Channel Label Frequency (GHz)
Wavelength
(nm)
B30.3 30.3 195.9 1530.33
31.1 195.8 1531.12
31.9 195.7 1531.90
32.6 195.6 1532.68
33.4 195.5 1533.47
B34.2 34.2 195.4 1534.25
35.0 195.3 1535.04
35.8 195.2 1535.82
36.6 195.1 1536.61
37.4 195 1537.40
B38.1 38.1 194.9 1538.19
38.9 194.8 1538.98
39.7 194.7 1539.77
40.5 194.6 1540.56
41.3 194.5 1541.35
