Cisco ONS 15454 DWDM Reference Manual

A-6
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.2.1 Power
Table A-2 Individual Card Power Requirements (Typical Values at 25 degrees C)
Card Type Card Name (Power in Watts) Amperes at –48 V BTU/Hr.
Common Control
Cards
TCC2/TCC2P 26 0.54 89
AIC-I 8 0.17 28
AEP 3 (from +5 VDC from
AIC-I)
10
MIC-A/P 0.13 via
TCC2/TCC2P/TCC3
0.44
MIC-C/T/P 0.38 via
TCC2/TCC2P/TCC3
1.29
MS-ISC-100T 53 1.10 181.0
Optical Service
Channel Cards
OSCM 23 0.48 79
OSC-CSM 24 0.5 82
Optical
Amplifier Cards
OPT-PRE 30 0.63 103
OPT-BST 30 0.63 103
OPT-BST-E 30 0.63 103
OPT-BST-L 25 0.52 86
OPT-AMP-L 32 0.67 110
OPT-AMP-17-C 40 0.83 137
OPT-AMP-C 40 0.83 137
Multiplexer and
Demultiplexer
Cards
32MUX-O 16 0.33 55
32DMX-O 16 0.33 55
4MD-xx.x 17 0.35 58.0
ROADM Cards
32DMX 15 0.31 52
32DMX-L 15 0.31 52
32WSS 50 1.04 171
32WSS-L 43 0.90 147
40-MUX-C 35 0.73 120
40-DMX-C 35 0.73 120
40-DMX-CE 35 0.73 120
40-WSS-C 73 1.53 250
40-WSS-CE 73 1.53 250
40-WXC-C 30 0.63 103
MMU 7 0.15 24

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
