1-17

Cisco ONS 15454 DWDM Reference Manual, R8.5

78-18343-02

Chapter 1 Shelf Assembly Hardware

1.4.2 Single Y-Cable Protection Module

Table 1-4 details the single-mode and multimode front panel Protection B mapping. It shows how two

DWDM receive inputs (client working and protect) provide one output signal to the equipment, using

the module combiner function.

Table 1-5 details the single-mode and multimode front panel Protection B mapping. It shows how the

module splits a single receive input from the equipment into two DWDM output signals (working and

protect) to the client.

The following muxponder (MXP) and transponder (TXP) cards can use Y-cable protection:

• MXP_2.5_10G

• MXP_2.5_10E

• MXP_MR_2.5G

• TXP_MR_10G

• TXP_MR_10E

• TXP_MR_2.5G

• MXP_MR_10DME_C

• MXP_MR_10DME_L

Table 1-3 Protection A (TXP Cards 1 and 2) Port Mapping: Splitter to DWDM

Receive Port Signal Source

10 (RXa) TX port on customer client equipment A

Transmit Port Signal Destinations

2 (TXa1) Client RX port on the TXP 1 card

7 (TXa2) Client RX on the TXP 2 card

Table 1-4 Protection B (TXP Cards 3 and 4) Port Mapping: Combiner from DWDM

Receive Port Signal Sources

3 (RXb1) Client TX port on the TXP 3 card

8 (RXb2) Client TX port on the TXP 4 card

Transmit Port Signal Destination

11 (TXb) RX port on customer client equipment B

Table 1-5 Protection B (TXP Cards 3 and 4) Port Mapping: Splitter to DWDM

Receive Port Number Signal Source

12 (RXb) TX port on customer client equipment B

Transmit Port Number Signal Destinations

4 (TXb1) Client RX on the TXP 3 port

9 (TXb2) Client RX on the TXP 4 port
