Cisco ONS 15454 DWDM Reference Manual

7-31
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 7 Reconfigurable Optical Add/Drop Cards
7.6.2 32DMX-L Block Diagram
Figure 7-15 32DMX-L Faceplate and Ports
7.6.2 32DMX-L Block Diagram
Figure 7-16 shows a block diagram of the 32DMX-L card.
145940
32DMX
FAIL
ACT
SF
98.0-04.0 91.2-97.1 84.5-90.4 77.8-83.6
COM
RX
TX
32 Drop Ports32 Drop Port Outputs
Logical View
Drop 1-8
Drop 9-16
Drop 17-24
Drop 25-32
COM RX
(Receives Drop-TX from
32WSS-L on COM RX)
COM-RX
Drop-1
Drop-2
Drop-32
MON

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
