Appendix A Hardware Specifications
A.9.14 GE_XP and 10GE_XP Card Specifications
– Code: Scrambled NRZ
– Fiber: 1310-nm single-mode for ONS-XC-10GS1 XFP or 1530.33 to 1554.94-nm single-mode
for ONS-XC-10G-xx.x XFP
– Maximum chromatic dispersion allowance: up to 3600 ps/nm
– Loopback modes: Terminal, facility, and cross-connect
– Connectors: LC
• Transmitter (trunk side)
– Transmitter: LN external modulator transmitter
– Maximum transmitter output power: Depends on XFP that is used
– Minimum transmitter output power: Depends on XFP that is used
– Wavelength stability (drift): +/– 25 picometers (pm)
• Receiver (trunk side)
– Receiver: APD
– Receiver input wavelength range: Depends on XFP that is used
– Receiver sensitivity: depends on XFP that is used
– Link loss budget: 24 dB minimum, with no dispersion or 22 dB optical path loss at
BER = 1 * 10 exp – 12 including dispersion
• Dimensions
– Height: 12.65 in. (321.3 mm)
– Width: 1.866 in. (47.4 mm) (The dimension of the finger gasket is not included)
– Depth: 9.00 in. (228.6 mm)
– Depth with backplane connector: 9.250 in. (235 mm)
– Weight not including clam shell: 5.07 lb (2.3 kg)
A.9.14 GE_XP and 10GE_XP Card Specifications
The GE_XP and 10GE-XP cards have the following specifications:
• Line (trunk side)
– Bit rate: 11.1 Gbps (in ITU-T G.709 Digital Wrapper/FEC mode) or 10.3125 Gbps (in ITU-T
G.709 Digital Wrapper/FEC mode disabled)
– Code: Scrambled NRZ
– Fiber: 1550-nm single-mode
– Maximum chromatic dispersion allowance: – 500 to 1600 ps/nm (specified penalty)
– Loopback modes: Terminal and facility
Caution You must use a 20-dB fiber attenuator (15 to 25 dB) when working with the GE_XP card in a loopback
on the trunk port. Do not use direct fiber loopbacks with the GE_XP card. Using direct fiber loopbacks
causes irreparable damage to the GE_XP card.
– Connectors: LC

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
