12-8
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 12 Cisco Transport Controller Operation
12.5 CTC Window
12.5 CTC Window
When you log into a single-shelf ONS 15454, the CTC window appears in node view (Figure 12-3).
When you log into a multishelf ONS 15454, meaning that two or more ONS 15454 shelves are
configured to operate as one node, the multishelf view (Figure 12-4) appears in the CTC window. The
window includes a menu bar, a toolbar, and a top and bottom pane. The top pane provides status
information about the selected objects and a graphic of the current view. The bottom pane provides tabs
and subtabs to view ONS 15454 information and perform ONS 15454 provisioning and maintenance
tasks. From the CTC window, you can display the other ONS 15454 views. In single-shelf mode, these
are the network, node, and card views. In multishelf mode, these are the network, multishelf, shelf, and
card views.
TL1 Refers to a connection to the ONS 15454
using TL1 rather than CTC. TL1 sessions can
be started from CTC, or you can use a TL1
terminal. The physical connection can be a
craft connection, corporate LAN, or a TL1
terminal.
Refer to the Cisco ONS SONET TL1
Reference Guide or the Cisco ONS 15454
SDH and Cisco ONS 15600 SDH TL1
Reference Guide.
Remote Refers to a connection made to the
ONS 15454 using a modem.
• A modem must be connected to the
ONS 15454.
• The modem must be provisioned for
the ONS 15454. To run CTC, the
modem must be provisioned for
Ethernet access.
Table 12-3 ONS 15454 Connection Methods (continued)
Method Description Requirements
