Cisco ONS 15454 DWDM Reference Manual

A-34
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.7.9 40-WSS-CE Card Specifications
Note For power specifications, see Table A-2 on page A-6.
The 40-WSS-CE card channel grid is listed in Table A-20.
Table A-19 40-WSS-C Card Optical Specifications
Parameter Note Condition Min Max Unit
Channel grid:
–0.1 dB
All SOP and within
whole operating
temperature range
EXP RX greater
than or equal to
COM TX
——pm
Channel grid:
–0.25 dB
+/– 61 — pm
Channel grid:
–0.5 dB
+/– 91 — pm
Channel grid:
–1.0 dB
+/– 135 — pm
Channel grid:
–0.1 dB
All SOP and within
whole operating
temperature range
Add 1, 40 greater
than or equal to
COM TX
+/– 32 — pm
Channel grid:
–0.25 dB
+/– 98 — pm
Channel grid:
–0.5 dB
+/– 135 — pm
Channel grid:
–1.0 dB
+/– 160 — pm
Insertion loss All SOP and within
whole operating
temperature range
EXP RX greater
than or equal to
COM TX
—7.5dB
COM RX greater
than or equal to EXP
TX
—2.3dB
Add 1, 40 greater
than or equal to
COM TX
—6.0dB
COM RX greater
than or equal to
DROP TX
—6.8dB
VOA dynamic range — EXP RX greater
than COM TX
20 — dB
Add 1, 40 greater
than or equal to
COM TX
25 — dB
Maximum optical
input power
— — 300 — mW

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
