Appendix A Hardware Specifications
A.7.3 32WSS Card Specifications
• Dimensions
– Height: 12.65 in. (321.3 mm)
– Width: 0.921 in. (23.4 mm) (The dimension of the finger gasket is not included)
– Depth: 9.00 in. (228.6 mm)
A.7.3 32WSS Card Specifications
The 32WSS card optical specifications are listed in Table A-10.
Note For power specifications, see Table A-2 on page A-6.
The 32WSS channel plan is shown in Table A-11. All 32WSS client interfaces must comply with this
plan.
Table A-10 32WSS Optical Specifications
Parameter Note Condition Min Typical Max Units
–0.25 dB bandwidth All SOP and within
whole operating
temperature range,
connectors
included, and for
maximum VOA
operating
attenuation.
EXP RX =>
COM TX
+/–/95 — — pm
–0.5 dB bandwidth +/–115 — — pm
–1.0 dB bandwidth +/–135 — — pm
–0.25 dB bandwidth Add 1, 32 =>
COM TX
+/–115 — — pm
–0.5 dB bandwidth +/–135 — — pm
–1.0 dB bandwidth +/–160 — — pm
Insertion loss All SOP, any
optical switch state,
and within whole
operating
temperature range,
connectors
included.
EXP RX =>
COM TX
— — 11.3 dB
— COM RX =>
EXP TX
—— 1.5dB
— Add 1, 32 =>
COM TX
—— 7.6dB
— COM RX =>
DROP TX
6—8.5dB
VOA dynamic range — EXP RX =>
COM TX
20 — — dB
— Add 1, 32 =>
COM TX
25 — — dB
Maximum optical
input power
— — 300 — — mW

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
