Cisco ONS 15454 DWDM Reference Manual

A-23
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.7.2 32DMX-L Card Specifications
The 32DMX card has the following additional specifications:
• Dimensions
– Height: 12.65 in. (321.3 mm)
– Width: 0.921 in. (23.4 mm) (The dimension of the finger gasket is not included)
– Depth: 9.00 in. (228.6 mm)
A.7.2 32DMX-L Card Specifications
The 32DMX-L card optical specifications are listed in Table A-6.
Note For power specifications, see Table A-2 on page A-6.
25 7 54.1 192.9 1554.13
26 54.9 192.8 1554.94
27 55.7 192.7 1555.75
28 56.5 192.6 1556.55
29 8 58.1 192.4 1558.17
30 58.9 192.3 1558.98
31 59.7 192.2 1559.79
32 60.6 192.1 1560.61
Table A-7 32DMX Channel Plan (continued)
Channel
Number Band Channel ID Frequency (GHz) Wavelength (nm)
Table A-8 32DMX -L Optical Specifications
Parameter Note Condition Min Typical Max Units
–1 dB
bandwidth
All SOP and within whole
operating temperature
range, connectors included,
and for maximum VOA
operating attenuation.
COM RX => TX 1, 32
(OUT)
+/–100 — — pm
–3 dB
bandwidth
+/–199 — — pm
Insertion loss All SOP, and within whole
operating temperature
range, connectors included.
COM RX => TX 1, 32 — — 5.8 dB
VOA
dynamic
range
— COM RX => TX 1, 32 25 — — dB
Maximum
optical input
power
——300——mW

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
