A.7.1 32DMX Card Specifications
The 32DMX channel plan is shown in Table A-7. All 32DMX client interfaces must comply with this
plan.
VOA
dynamic
range
— COM RX => TX 1, 32 25 — — dB
Maximum
optical input
power
——300——mW
Table A-6 32DMX Optical Specifications (continued)
Parameter Note Condition Min Typical Max Units
Table A-7 32DMX Channel Plan
Channel
Number Band Channel ID Frequency (GHz) Wavelength (nm)
1 1 30.3 195.9 1530.33
2 31.2 195.8 1531.12
3 31.9 195.7 1531.90
4 32.6 195.6 1532.68
5 2 34.2 195.4 1534.25
6 35.0 195.3 1535.04
7 35.8 195.2 1535.82
8 36.6 195.1 1536.61
9 3 38.1 194.9 1538.19
10 38.9 194.8 1538.98
11 39.7 194.7 1539.77
12 40.5 194.6 1540.56
13 4 42.1 194.4 1542.14
14 42.9 194.3 1542.94
15 43.7 194.2 1543.73
16 44.5 194.1 1544.53
17 5 46.1 193.9 1546.12
18 46.9 193.8 1546.92
19 47.7 193.7 1547.72
20 48.5 193.6 1548.51
21 6 50.1 193.4 1550.12
22 50.9 193.3 1550.92
23 51.7 193.2 1551.72
24 52.5 193.1 1552.52
