2-20
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 2 Common Control Cards
2.6.1 MIC-A/P FMEC
Table 2-13 Alarm Interface Pinouts on the MIC-A/P DB-62 Connector
Pin No. Signal Name Signal Description
1 ALMCUTOFF N Alarm cutoff, normally open ACO pair
2 ALMCUTOFF P Alarm cutoff, normally open ACO pair
3 ALMINP0 N Alarm input pair 1, reports closure on connected wires
4 ALMINP0 P Alarm input pair 1, reports closure on connected wires
5 ALMINP1 N Alarm input pair 2, reports closure on connected wires
6 ALMINP1 P Alarm input pair 2, reports closure on connected wires
7 ALMINP2 N Alarm input pair 3, reports closure on connected wires
8 ALMINP2 P Alarm input pair 3, reports closure on connected wires
9 ALMINP3 N Alarm input pair 4, reports closure on connected wires
10 ALMINP3 P Alarm input pair 4, reports closure on connected wires
11 EXALM0 N External customer alarm 1
12 EXALM0 P External customer alarm 1
13 GND Ground
14 EXALM1 N External customer alarm 2
15 EXALM1 P External customer alarm 2
16 EXALM2 N External customer alarm 3
17 EXALM2 P External customer alarm 3
18 EXALM3 N External customer alarm 4
19 EXALM3 P External customer alarm 4
20 EXALM4 N External customer alarm 5
21 EXALM4 P External customer alarm 5
22 EXALM5 N External customer alarm 6
23 EXALM5 P External customer alarm 6
24 EXALM6 N External customer alarm 7
25 EXALM6 P External customer alarm 7
26 GND Ground
27 EXALM7 N External customer alarm 8
28 EXALM7 P External customer alarm 8
29 EXALM8 N External customer alarm 9
30 EXALM8 P External customer alarm 9
31 EXALM9 N External customer alarm 10
32 EXALM9 P External customer alarm 10
33 EXALM10 N External customer alarm 11
34 EXALM10 P External customer alarm 11
35 EXALM11 N External customer alarm 12
36 EXALM11 P External customer alarm 12
