8-45
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 8 Transponder and Muxponder Cards
8.9 MXP_MR_2.5G and MXPP_MR_2.5G Cards
Note In Software Release 7.0 and later, two additional operating modes have been made available to the user:
pure ESCON (all 8 ports running ESCON), and mixed mode (Port 1 running FC/GE/FICON, and Ports
5 through 8 running ESCON). When the card is part of a system running Software Release 6.0 or below,
only one operating mode, (FC/GE) is available for use.
The 2.5-Gbps Multirate Muxponder–Protected–100 GHz–Tunable 15xx.xx-15yy.yy (MXPP_MR_2.5G)
card aggregates various client SAN service client inputs (GE, FICON, Fibre Channel, and ESCON) into
one 2.5 Gbps STM-16/OC-48 DWDM signal on the trunk side. It provides two long-reach
STM-16/OC-48 ports per card and is compliant with ITU-T G.957 and Telcordia GR-253-CORE.
Because the cards are tunable to one of four adjacent grid channels on a 100-GHz spacing, each card is
available in eight versions, with 15xx.xx representing the first wavelength and 15yy.yy representing the
last wavelength of the four available on the card. In total, 32 DWDM wavelengths are covered in
accordance with the ITU-T 100-GHz grid standard, G.692, and Telcordia GR-2918-CORE, Issue 2. The
card versions along with their corresponding wavelengths are shown in Table 8-22.
The muxponders are intended to be used in applications with long DWDM metro or regional
unregenerated spans. Long transmission distances are achieved through the use of flat gain optical
amplifiers.
The client interface supports the following payload types:
• 2G FC
• 1G FC
• 2G FICON
• 1G FICON
• GE
• ESCON
Note Because the client payload cannot oversubscribe the trunk, a mix of client signals can be accepted, up to
a maximum limit of 2.5 Gbps.
Table 8-22 Card Versions
Card Version Frequency Channels at 100 GHz (0.8 nm) Spacing
1530.33–1532.68 1530.33 nm 1531.12 nm 1531.90 nm 1532.68 nm
1534.25–1536.61 1534.25 nm 1535.04 nm 1535.82 nm 1536.61 nm
1538.19–1540.56 1538.19 nm 1538.98 nm 1539.77 nm 1540.56 nm
1542.14–1544.53 1542.14 nm 1542.94 nm 1543.73 nm 1544.53 nm
1546.12–1548.51 1546.12 nm 1546.92 nm 1547.72 nm 1548.51 nm
1550.12–1552.52 1550.12 nm 1550.92 nm 1551.72 nm 1552.52 nm
1554.13–1556.55 1554.13 nm 1554.94 nm 1555.75 nm 1556.55 nm
1558.17–1560.61 1558.17 nm 1558.98 nm 1559.79 nm 1560.61 nm
