5.1.3 Interface Classes
Table 5-5 lists the optical interface performance parameters for 2.5-Gbps cards that provide signal input
to multiplexer and demultiplexer cards.
10-Gbps multirate
transponder/10-Gbps
FEC transponder
(TXP_MR_10E)
+3.0 to 6.0 dBm +3.0 to 6.0 dBm — +3.0 to 6.0 dBm
Dispersion
compensation
tolerance
+/–800 ps/nm +/–1,000 ps/nm +/–1,000
ps/nm
+/–800 ps/nm
1. OSNR = optical signal-to-noise ratio
2. BER = bit error rate
3. These values, decreased by patchcord and connector losses, are also the input power values for the OADM cards.
Table 5-4 10-Gbps Interface Optical Performance (continued)
Parameter Class A Class B Class C Class I
Type
Power
Limited
OSNR
1
Limited
Power
Limited
OSNR
Limited
OSNR
Limited
Power
Limited
OSNR
Limited
Table 5-5 2.5-Gbps Interface Optical Performance
Parameter Class D Class E Class F Class G Class H Class J
Type
Power
Limited
OSNR
Limited
Power
Limited
OSNR
Limited
OSNR
Limited
Power
Limited
OSNR
Limited
Power
Limited
OSNR
Limited
Power
Limited
Maximum bit rate 2.5 Gbps 2.5 Gbps 2.5 Gbps 2.5 Gbps 1.25 Gbps 2.5 Gbps
Regeneration 3R 3R 2R 3R 3R 3R
FEC Yes No No No No No
Threshold Average Average Average Average Average Average
Maximum BER 10
–15
10
–12
10
–12
10
–12
10
–12
10
–12
OSNR sensitivity 14 dB 6 dB 14 dB 10 dB 15 dB 14 dB 11 dB 13 dB 8 dB 12 dB
Power sensitivity –31
dBm
–25
dBm
–30
dBm
–23
dBm
–24 dBm –27
dBm
–33
dBm
–28 dBm –18 dBm –26 dBm
Power overload –9 dBm –9 dBm –9 dBm –9 dBm –7 dBm –17dBm
Transmitted Power Range
1
TXP_MR_2.5G –1.0 to 1.0 dBm –1.0 to 1.0 dBm –1.0 to
1.0 dBm
–2.0 to 0 dBm
TXPP_MR_2.5G –4.5 to –2.5 dBm –4.5 to –2.5 dBm –4.5 to
–2.5 dBm
MXP_MR_2.5G — +2.0 to +4.0 dBm —
MXPP_MR_2.5G — –1.5 to +0.5 dBm —
To Next Page
