Chapter 1 Shelf Assembly Hardware
1.5 Typical DWDM Rack Layouts
Figure 1-16 Y-Cable Protection Port Label
1.5 Typical DWDM Rack Layouts
Typical dense wavelength division multiplexing (DWDM) applications might include:
• 3 ONS 15454 shelves
• 1 Dispersion Compensating Unit (DCU)
• 7 patch panels (or fiber-storage trays), in either 1rack unit (RU)or 2 RU sizes
– 1RU: Fiber-storage tray and 64-channel patch panel
– 2 RU: Y-cable patch panel, 64-channel patch panel, 80-channel patch panel, and mesh patch
panel (4 or 8 degree)
Or, alternatively:
• 3 ONS 15454 shelves
• 2 DCUs
• 6 standard patch-panel trays (or fiber-storage trays), or 3 deep patch-panel trays, in either 1 RU or
2 RU sizes
– 1RU: Fiber-storage tray and 64-channel patch panel
– 2 RU: Y-cable patch panel, 64-channel patch panel, 80-channel patch panel, and mesh patch
panel (4 or 8 degree)
See Figure 1-17 for a typical rack layout.
Note Use the rack layout generated by Cisco TransportPlanner to determine your exact shelf layout.
Client TX
Client RX
TXP W TX
TXP W RX TXP W RX TXP W RX TXP W RXTXP W RX TXP W RX TXP W RX TXP W RX
TXP P RX
TXP P TX TXP P TX TXP P TX TXP P TX TXP P TX TXP P TX TXP P TX TXP P TX
TXP P RX TXP P RX TXP P RX TXP P RX TXP P RX TXP P RX TXP P RX
TXP W TX TXP W TX TXP W TX TXP W TX TXP W TX TXP W TX TXP W TX
Client RX Client RX Client RX Client RX Client RX Client RX Client RX
Client TX Client TX Client TX Client TX Client TX Client TX Client TX
#1 #2 #3 #4 #5 #6 #7 #8
144677

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
