Appendix A Hardware Specifications
A.9.11 TXP_MR_10E_C Card Specifications
• Receiver (trunk side, see Table A-43)
– Receiver: APD
– Link loss budget: 24 dB minimum, with no dispersion or 22 dB optical path loss at
BER = 1 * 10 exp – 12 including dispersion
– Receiver input wavelength range: 1529 to 1562 nm
• Line (client side):
– XFP-based SR
27 194.70 1539.766 68 192.65 1556.151
28 194.65 1540.162 69 192.60 1556.555
29 194.60 1540.557 70 192.55 1556.959
30 194.55 1540.953 71 192.50 1557.36
31 194.50 1541.35 72 192.45 1557.77
32 194.45 1541.75 73 192.40 1558.173
33 194.40 1542.142 74 192.35 1558.578
34 194.35 1542.539 75 192.30 1558.983
35 194.30 1542.936 76 192.25 1559.389
36 194.25 1543.333 77 192.20 1559.794
37 194.20 1543.730 78 192.15 1560.200
38 194.15 1544.128 79 192.10 1560.606
39 194.10 1544.526 80 192.05 1561.013
40 194.05 1544.924 81 192.00 1561.42
41 194.00 1545.32 82 191.95 1561.83
Table A-42 TXP_MR_10E_C Card Trunk Wavelengths (continued)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Table A-43 TXP_MR_10E _C Card Receiver Trunk Side Specifications
OSNR
1
1. OSNR defined with 0.1 nm RBW
FEC Type Pre-FEC BER Post-FEC BER
Input Power
Sensitivity
2
2. Receiver filter bandwidth greater than or equal to 180 pm (at – 3 dBm)
Chromatic Dispersion
Tolerance
30 dB Off < 10 exp – 12 N/A – 8 to – 20 dBm +/– 1200 ps/nm
26 dB Off < 10 exp – 12 N/A – 8 to – 20 dBm + – 1000 ps/nm
26 dB Off < 10 exp – 12 N/A – 8 to – 22 dBm —
17 dB Standard < 10 exp – 5 < 10 exp – 15 – 8 to – 18 dBm +/– 800 ps/nm
15.5 dB Standard < 10 exp – 5 < 10 exp – 15 – 8 to – 18 dBm —
14 dB Enhanced < 7 x 10 exp – 4 < 10 exp – 15 – 8 to – 18 dBm +/– 800 ps/nm
12 dB Enhanced < 7 x 10 exp – 4 < 10 exp – 15 – 8 to – 18 dBm —
