Cisco ONS 15454 DWDM - Card Compatibility; Table 8-1 Cisco ONS 15454 Transponder and Muxponder Cards

8-3
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 8 Transponder and Muxponder Cards
8.1.2 Card Compatibility
8.1.2 Card Compatibility
Table 8-2 lists the Cisco Transport Controller (CTC) software compatibility for each TXP, TXPP, MXP,
MXPP, 10GE_XP, GE_XP and ADM-10G card.
Table 8-1 Cisco ONS 15454 Transponder and Muxponder Cards
Card Port Description For Additional Information
TXP_MR_10G
The TXP_MR_10G card has two sets of
ports located on the faceplate.
See the “8.3 TXP_MR_10G
Card” section on page 8-8
TXP_MR_10E
The TXP_MR_10E card has two sets of
ports located on the faceplate.
See the “8.4 TXP_MR_10E
Card” section on page 8-11
TXP_MR_10E_C and
TXP_MR_10E_L
The TXP_MR_10E_C and
TXP_MR_10E_L cards have two sets of
ports located on the faceplate.
See the “8.5 TXP_MR_10E_C
and TXP_MR_10E_L Cards”
section on page 8-16
TXP_MR_2.5G
The TXP_MR_2.5G card has two sets of
ports located on the faceplate.
See the “8.6 TXP_MR_2.5G
and TXPP_MR_2.5G Cards”
section on page 8-20
TXPP_MR_2.5G
The TXPP_MR_2.5G card has three sets of
ports located on the faceplate.
See the “8.6 TXP_MR_2.5G
and TXPP_MR_2.5G Cards”
section on page 8-20
MXP_2.5G_10G
The MXP_2.5G_10G card has nine sets of
ports located on the faceplate.
See the “8.7 MXP_2.5G_10G
Card” section on page 8-24.
MXP_2.5G_10E
The MXP_2.5G_10E card has nine sets of
ports located on the faceplate.
See the “8.7.4 MXP_2.5G_10E
Card” section on page 8-28
MXP_2.5G_10E_C and
MXP_2.5G_10E_L
The MXP_2.5G_10E_C and
MXP_2.5G_10E_L cards have nine sets of
ports located on the faceplate.
See the “8.8 MXP_2.5G_10E_C
and MXP_2.5G_10E_L Cards”
section on page 8-35
MXP_MR_2.5G
The MXP_MR_2.5G card has nine sets of
ports located on the faceplate.
See the “8.9 MXP_MR_2.5G
and MXPP_MR_2.5G Cards”
section on page 8-44
MXPP_MR_2.5G
The MXPP_MR_2.5G card has ten sets of
ports located on the faceplate.
See the “8.9 MXP_MR_2.5G
and MXPP_MR_2.5G Cards”
section on page 8-44
MXP_MR_10DME_C
and
MXP_MR_10DME_L
The MXP_MR_10DME_C and
MXP_MR_10DME_L cards have eight sets
of ports located on the faceplate.
See the
“8.10 MXP_MR_10DME_C
and MXP_MR_10DME_L
Cards” section on page 8-51
GE_XP
The GE_XP has 20 GE client ports and two
10GE trunk ports.
See the “8.11 GE_XP and
10GE_XP Cards” section on
page 8-59
10GE_XP
The 10GE_XP has two 10 Gigabit Ethernet
(GE) client ports and two 10GE trunk ports.
See the “8.11 GE_XP and
10GE_XP Cards” section on
page 8-59
ADM-10G
The ADM-10G has 18 sets of ports located
on the faceplate.
See the “8.12 ADM-10G Card”
section on page 8-68
