Appendix A      Hardware Specifications
A.3.3    AIC-I Card Specifications
 –
Normal operation: –40.5 to –56.7 V (in –48 VDC systems)
 –
Undervoltage: Major alarm
 –
Overvoltage: Major alarm
 • Dimensions
 –
Height: 12.650 in. (321.3 mm)
 –
Width: 0.921 in. (23.4 mm) (The dimension of the finger gasket is not included)
 –
Depth: 9.000 in. (228.6 mm)
 –
Depth with backplane connector: 9.250 in. (235 mm)
 –
Weight not including clam shell: 1.5 lb (0.7 kg)
A.3.3 AIC-I Card Specifications
The AIC-I card has the following specifications:
 • Alarm inputs
 –
Number of inputs: 12 without AEP, 32 with AEP
 –
Opto-coupler isolated
 –
Label customer provisionable
 –
Severity customer provisionable
 –
Common 32 V output for all alarm inputs
 –
Each input limited to 2 mA
 –
Termination: Wire-wrap on backplane without AEP, on AEP connectors with AEP
 • Alarm outputs
 –
Number of outputs: 4 (user configurable as inputs) without AEP, 16 with AEP
 –
Switched by opto MOS (metal oxide semiconductor)
 –
Triggered by definable alarm condition
 –
Maximum allowed open circuit voltage: 60 VDC
 –
Maximum allowed closed circuit current: 100 mA
 –
Termination: Wire-wrap on backplane without AEP, on AEP connectors with AEP
 • Express orderwire/local orderwire (EOW/LOW)
 –
ITU-T G.711, ITU-T G.712, Telcordia GR-253-CORE
 –
A-law, mu-law
Note Due to the nature of mixed coding, in a mixed-mode (A-law/mu-law) configuration, the
orderwire is not ITU-T G.712 compliant.
 –
Orderwire party line
 –
Dual tone, multifrequency (DTMF) signaling
 • User data channel (UDC)
 –
Bit rate: 64 kbps, codirectional
