8-71
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 8 Transponder and Muxponder Cards
8.12.5 Client Interfaces
Figure 8-28 ADM-10G Card Port Capacities
8.12.5 Client Interfaces
The ADM-10G card uses LC optical port connectors and, as shown in Figure 8-28, supports up to 16
SFPs that can be utilized for OC-N/STM-N traffic. Eight of the SFPs can be used for Gigabit Ethernet.
The interfaces can support any mix of OC-3/STM-1, OC-12/STM-4, OC-48/STM-16, or Gigabit
Ethernet of any reach, such as SX, LX, ZX, SR, IR, or LR. The interfaces support a capacity of:
• 4 x OC-48/STM-16
• 16 x OC-12/STM-4
• 16 x OC-3/STM-1
• 8 x GE
The supported client SFPs are:
• Gray SFPs
–
1000Base-SX SFP 850 nm (ONS-SE-G2F-SX=)
–
1000Base-LX SFP 1310 nm (ONS-SE-G2F-LX=)
–
OC48/STM16 IR1, OC12/STM4 SR1, OC3/STM1 SR1, GE-LX multirate SFP 1310 nm
(ONS-SE-Z1=)
–
OC3/STM1 IR1, OC12/STM4 IR1 multirate SFP 1310 nm (ONS-SI-622-I1=)
–
OC48/STM16 SR1 SFP 1310 nm (ONS-SI-2G-S1=)
–
OC48/STM16 IR1 SFP 1310 nm (ONS-SI-2G-I1=)
• Colored DWDM SFPs
–
1000Base-ZX SFP 1550 nm (ONS-SI-GE-ZX=)
–
OC3/STM1 LR2 SFP 1550 nm (ONS-SI-155-L2=)
–
OC48/STM16 LR2 SFP 1550 nm (ONS-SI-2G-L2=)
–
OC48/STM16 SFP (ONS-SC-2G-xx.x)
GE Gray SFP 1
13
14
15
16
ILK1
(17)
ILK2
(18)
TRK1
(19)
2
3
4
5
6
7
8
9
10
11
12
GE Gray SFP
GE Gray SFP
GE
OC48/OC12/OC3
OC48/OC12/OC3
OC48/OC12/OC3
OC48/OC12/OC3
STM16/STM4/STM1
STM16/STM4/STM1
STM16/STM4/STM1
STM16/STM4/STM1
Gray SFP
Gray SFP
Gray XFP
Gray XFP
DWDM XFP OTU2/OC192/STM64
Gray SFP
Gray SFP
Gray SFP
GE Gray SFP
GE Gray SFP
GE Gray SFP
Gray SFP
GE
or
or
or
or
or
or
or
or
or
or
or
or
or
or
or
or
or
or
or
or
Gray SFP
Gray SFP
Gray SFP
OC12/OC3
OC12/OC3
OC12/OC3
OC12/OC3
OC12/OC3
OC12/OC3
OC12/OC3
OC12/OC3
OC12/OC3
OC12/OC3
OC12/OC3
OC12/OC3
STM4/STM1
STM4/STM1
STM4/STM1
STM4/STM1
STM4/STM1
STM4/STM1
STM4/STM1
STM4/STM1
STM4/STM1
STM4/STM1
STM4/STM1
STM4/STM1 Gray SFP
OC192/STM64
OC192/STM64
240289
