Cisco ONS 15454 DWDM Reference Manual, R8.5

78-18343-02

Chapter 8 Transponder and Muxponder Cards

8.2 Safety Labels

This section explains the significance of the safety labels attached to some of the cards. The faceplates

of the cards are clearly labeled with warnings about the laser radiation levels. You must understand all

warning labels before working on these cards.

8.2.1 Class 1 Laser Product Cards

The MXP_2.5G_10G, MXP_2.5G_10E, MXP_2.5G_10E_C, MXP_2.5G_10E_L, ADM-10G, GE_XP,

and 10GE_XP cards have Class 1 lasers. The labels that appear on these cards are described in the

following sections.

8.2.1.1 Class 1 Laser Product Label

The Class 1 Laser Product label is shown in Figure 8-1.

Table 8-2 Software Release Compatibility for Transponder and Muxponder Cards

Card Name R4.5 R4.6 R4.7 R5.0 R6.0 R7.0 R7.2 R8.0 R8.5

TXP_M R_10G Yes Yes Yes Yes Ye s Ye s Ye s Yes Ye s

TXP_MR_10E No No Yes Yes Yes Yes Yes Yes Yes

TXP_MR_10E_C NoNoNoNoNoYesYesYesYes

TXP_MR_10E_L NoNoNoNoNoYesYesYesYes

TXP_M R_2.5 G Yes Yes Yes Yes Ye s Ye s Ye s Yes Yes

TXPP _M R_2. 5G Yes Yes Yes Yes Ye s Ye s Yes Yes Ye s

MXP_ 2.5G_1 0G Yes Yes Ye s Ye s Yes Yes Ye s Ye s Yes

MXP_ 2.5G_1 0E No No Ye s Ye s Yes Yes Ye s Ye s Yes

MXP_2.5G_10E_C No No No No No Yes Yes Yes Yes

MXP_2.5G_10E_L No No No No No Yes Yes Yes Yes

MXP_MR_2.5G No No Yes Yes Yes Yes Yes Yes Yes

MXPP_MR_2.5G No No Yes Yes Yes Yes Yes Yes Yes

MXP_MR_10DME_C No No No No No Yes Yes Yes Yes

MXP_MR_10DME_L No No No No No Yes Yes Yes Yes

GE_XP NoNoNoNoNoNoNoYesYes

10GE_XP NoNoNoNoNoNoNoYesYes

ADM-10G NoNoNoNoNoNoNoYesYes
