9.3.3 Optical Side Configurations
Table 9-7 shows a four-degree mesh node provisioned as an upgrade. In the example, Sides A through
D are assigned to Slots 1 through 4. and 12 through 17 in Shelves 1and 2. 40-WXC-C cards in XC
termination mode are installed in Sides A and B, and 40-WXC-C cards in line termination mode are
installed in Sides C and D.
Table 9-8 shows an eight-degree mesh node. In the example, Sides A through H are assigned to Slots 1
through 6 in Shelf 1, Slots 1 through 6 and 12 through 17 in Shelves 2 through 4, and Slots 1 through 6
in Shelf 5. 40-WXC-C cards in line termination mode are installed in Sides A through H.
4WXC Line
Termination
D TXP/MXP —
5 TXP/MXP — TXP/MXP —
6 TXP/MXP — TXP/MXP —
7 TXP/MXP — TXP/MXP —
8 TXP/MXP — TXP/MXP —
Table 9-6 Multishelf Four-Degree Protected Mesh Node Layout Example (continued)
Shelf Slots 1–6 Side Slots 12–17 Side
Table 9-7 Multishelf Four-Degree Mesh Node Upgrade Layout Example
Shelf Slots 1–6 Side Slots 12–17 Side
1 WXC XC
Termination
A WXC XC
Termination
B
2WXC Line
Termination
CWXC Line
Termination
D
3 TXP/MXP — TXP/MXP —
4 TXP/MXP — TXP/MXP —
5 TXP/MXP — TXP/MXP —
6 TXP/MXP — TXP/MXP —
7 TXP/MXP — TXP/MXP —
8 TXP/MXP — TXP/MXP —
Table 9-8 Multishelf Eight-Degree Mesh Node Layout Example
Shelf Slots 1–6 Side Slots 12–17 Side
1WXC Line
Termination
A TXP/MXP —
2WXC Line
Termination
BWXC Line
Termination
C
3WXC Line
Termination
DWXC Line
Termination
E
4WXC Line
Termination
FWXC Line
Termination
G

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
