Chapter 17 Performance Monitoring
17.2.3 OTN PM Window
sets the values on the card to zero. All counters on the card are cleared. The Help button activates context
sensitive help. For more information about provisioning optical transport network (OTN) settings, refer
to the Cisco ONS 15454 DWDM Procedure Guide.
Table 17-11 lists the OTN PM provisioning options for all transponder, muxponder, GE_XP, and
10GE_XP cards. The options selected in the Provisioning tab affects the parameters displayed in the
Performance > OTN PM tab.
Table 17-11 Transponder and Muxponder PM Provisioning Options
Card OTN Provisioning
1
MXPP_MR_2.5G —
MXP_2.5G_10E G.709
FEC
FEC Thresholds
MXP_2.5G_10E_C G.709
FEC
FEC Thresholds
MXP_2.5G_10E_L G.709
FEC
FEC Thresholds
MXP_2.5G_10G G.709
FEC
FEC Thresholds
MXP_MR_2.5G —
MXP_MR_10DME_C G.709
FEC
FEC Thresholds
MXP_MR_10DME_L G.709
FEC
FEC Thresholds
TXPP_MR_2.5G G.709
FEC
FEC Thresholds
TXP_MR_10E G.709
FEC
FEC Thresholds
TXP_MR_10E_C G.709
FEC
FEC Thresholds
TXP_MR_10E_L G.709
FEC
FEC Thresholds
TXP_MR_10G G.709
FEC
FEC Thresholds

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
