Cisco ONS 15454 DWDM Reference Manual

A-28
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.7.4 32WSS-L Card Specifications
The 32WSS-L card has the following additional specifications:
• Dimensions
– Height: 12.65 in. (321.3 mm)
Table A-13 32WSS-L Channel Plan
Band ID Channel Label Frequency (THz) Wavelength (nm)
B77.8 77.8 190 1577.86
78.6 189.9 1578.69
79.5 189.8 1579.52
80.3 189.7 1580.35
B81.1 81.1 189.6 1581.18
82.0 189.5 1582.02
82.8 189.4 1582.85
83.6 189.3 1583.69
B84.5 84.5 189.2 1584.53
85.3 189.1 1585.36
86.2 189 1586.20
87.0 188.9 1587.04
B87.8 87.8 188.8 1587.88
88.7 188.7 1588.73
89.5 188.6 1589.57
90.4 188.5 1590.41
B91.2 91.2 188.4 1591.26
92.1 188.3 1592.10
92.9 188.2 1592.95
93.7 188.1 1593.79
B94.6 94.6 188 1594.64
95.4 187.9 1595.49
96.3 187.8 1596.34
97.1 187.7 1597.19
B98.0 98.0 187.6 1598.04
98.8 187.5 1598.89
99.7 187.4 1599.75
00.6 187.3 1600.60
B01.4 01.4 187.2 1601.46
02.3 187.1 1602.31
03.1 187 1603.17
04.0 186.9 1604.03

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
