Chapter 17 Performance Monitoring
17.3.3 4MD-xx.x Card Performance Monitoring Parameters
17.3.3 4MD-xx.x Card Performance Monitoring Parameters
The PM parameters for the 4MD-xx.x cards are listed in Table 17-19. For ONS 15454 optics definitions,
see the “17.4 Optics and 8b10b PM Parameter Definitions” section on page 17-20.
17.3.4 OADM Channel Filter Card Performance Monitoring Parameters
The PM parameters for the AD-1C-xx.x, AD-2C-xx.x, and AD-4C-xx.x cards are listed in Table 17-20.
For ONS 15454 optics definitions, see the “17.4 Optics and 8b10b PM Parameter Definitions” section
on page 17-20.
17.3.5 OADM Band Filter Card Performance Monitoring Parameters
The PM parameters for the AD-1B-xx.x and AD-4B-xx.x cards are listed in Table 17-21. For ONS 15454
optics definitions, see the “17.4 Optics and 8b10b PM Parameter Definitions” section on page 17-20.
17.3.6 Optical Service Channel Card Performance Monitoring Parameters
For ONS 15454 ANSI nodes, Figure 17-3 shows where overhead bytes detected on the ASICs produce
PM parameters for the OSCM and OSC-CSM cards.
Table 17-18 Optical PM Parameters for 2MUX-O, 32WSS, 32WSS-L, 32DMX, 32DMX-L, 32DMX-O,
40-WSS-C, 40-WSS-CE, 40-WXC-C, 40-DMX-C, 40-DMX-CE, and 40-MUX-C Cards
Optical Channel Optical Line
OPR OPT
Table 17-19 Optical PM Parameters for 4MD-xx.x Cards
Optical Channel Optical Band
OPR OPT
Table 17-20 Optical PM Parameters for AD-1C-xx.x, AD-2C-xx.x, and AD-4C-xx.x Cards
Optical Channel Optical Line
OPR OPT
Table 17-21 Optical PM Parameters for AD-1B-xx.x and AD-4B-xx.x Cards
Optical Line Optical Band
OPR OPT
