5-13
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 5 Multiplexer and Demultiplexer Cards
5.3 32MUX-O Card
Figure 5-11 32MUX-O Faceplate
For information on safety labels for the card, see the “5.2.1 Class 1 Laser Product Labels” section on
page 5-8.
Figure 5-12 shows a block diagram of the 32MUX-O card.
30.3 - 36.638.1 - 44.546.1 - 52.554.1 - 60.6
32MUX-0
COM
TX
RX
MON
FAIL
ACT
SF
96468
